| TE602 Specifications |
| # OF CHANNELS |
2 |
| MINIMUM SINGLE CHANNEL IMPEDANCE |
1 |
| CLASS |
A/B |
| AMP OPTIMIZED FOR |
FULL |
| POWER SUPPLY |
Semi Unregulated MOSFET
(Pat. No: US05598325) |
x |
| THD + NOISE (1 Watt) |
≤.1% |
| FREQUENCY RESPONSE (-3dB) |
20Hz-20KHz |
| SIGNAL-TO-NOISE RATIO (1 Watt) |
75 dB |
| OVERLOAD PROTECTION |
x |
| THERMAL PROTECTION |
x |
| 14.4VDC POWER |
4
|
100 X 2 |
| 2
|
225 X 2 |
| 1
|
300 X 2 |
| 4
Bridged |
450 X 1 |
| 2
Bridged |
600 X 1 |
| Peak Power |
1200 |
| BI-LEVEL INPUT (RCA Connection) |
Low Level |
x |
| Hi Level w/ Smart Engage (Pat. No: US06556683) |
x |
| INPUT SWITCH |
Input Sense 100mV-1V/1V-10V |
x |
| GAIN CONTROL |
Stereo - 100mV-10V |
x |
| CROSSOVER |
HI, 12dB / LOW, 24dB MONO @ 40Hz-350Hz, DEFEAT |
x |
| EQUALIZATION |
QUASI PARAMETRIC: BOOST/CUT
±12Db, FREQ. 30Hz-80Hz |
x |
| ARC: CUT 0-15dB, FREQ. 200Hz |
x |
| OTHER FEATURES |
Remote Subwoofer Level Control Parallelable |
x |
| Prizm EFX With Demo Mode |
x |
| POWER CONNECTION |
4 Gauge Direct Input With 8 Gauge Direct Cap Input |
x |
| DIMENSIONS |
Height |
9-5/8" |
| Width |
20-11/16" |
| Depth |
2-1/2" |
