Click For More Images
Click for more Images

Quick Install Settings
Quick Install Wiring
Owner's Manual

StreetWires

Amplifier Dimensions

TA3401 Specifications
# of Channels 1
Minimum Single Channel Impedance 2
Class D (Patented Adaptive Class D)
(Pat. No: US06753729)
x
Amp Type Optimized for Subwoofer x
Power Supply Semi Unregulated MOSFET (Pat. No: US05598325) x
THD + Noise (1 Watt) 0.5%
Signal-To-Noise Ratio (1 Watt) 72 dB
Overload Protection x
Thermal Protection x
Xtant Technology Cooling Continuously Variable Fan Speed x
Connection Terminals StreetWires Connectors x
14.4VDC Power 4 Ω 200W
2 Ω 400W
INPUT (RCA Connection) Low Level x
Hi Level w/ Smart Engage
(Pat. No: US06556683)
x
INPUT SWITCH Input Sense 100mV-1V/1V-10V x
GAIN CONTROL Mono - 100mV-10V x
CROSSOVER Low @ 40Hz-200Hz, 24dB x
EQUALIZATION ThunderEQ: Boost 0-18dB, Freq. 40Hz x
OTHER FEATURES Remote Subwoofer Level Control Parallelable x
FUSE RATING Total 50
Quantity x Fuse Value 2 x 25
DIMENSIONS Width 12-11/16"
Depth 9-5/8"
Height 2-1/2"




Testimonials: (Edited for grammar and length)

Very Nice
Reviewer: BTLOVE from Chester, VA on Tue Jul 12 23:55:15 EDT 2005
This amp is very nice. I drive a 2003 Ranger Single Cab and I’ve never had a system before. In the past 2 months… I [installed] this MTX Audio Thunder 3401 amp…and it freakin’ rumbles! These things just dump out bass. For me, this combination is perfect. I listen to everything from Lifehouse to Atreyu to Lil'Jon and it all sounds so good. This amp…is amazing. It has the built-in fan and even in the daytime the lights on this thing look really good. You can change the color of the lights and they can even pulsate to music you're listening to. This amp is a steal for the price, in my opinion.

Nice Product
Reviewer: Deman from Texas on Sat Jul 23 08:51:21 EDT 2005
Good amp. [It] pushes my 10” really nicely. Highly recommended.

This is a great amp
Reviewer: KSM from Portland, OR on Sat Sep 17 21:05:00 EDT 2005
OK, this is a great sub amp. I have had systems where I spent $15k and trust me this is a solid amp…it pushes [my sub] wonderfully. The specs are low on the amp. Each has actual specs from the manufacturer…[inside] the box. Mine came in at 472 [watts] not 400. [You] can't go wrong with this.
