Car Audio Amplifiers

TA3404 Specifications
# of Channels		4
Minimum Single Channel Impedance		2
Class	A/B (Patented Pure N-Channel) (Pat. No: US05631608, US05783970)	x
Amp Type	Full Range	x
Power Supply	Semi Unregulated MOSFET (Pat. No: US05598325)	x
THD + Noise (1 Watt)		0.25%
Signal-To-Noise Ratio (1 Watt)		78 dB
Overload Protection		x
Thermal Protection		x
Xtant Technology Cooling	Continuously Variable Fan Speed	x
Connection Terminals	StreetWires Connectors	x
14.4VDC Power	4 $Ω$	50W x 4
	2 $Ω$	100W x 4
	4 Bridged	200W x 2
	2 Bridged	400W x 1
INPUT (RCA Connection)	Low Level	x
INPUT (RCA Connection)	Hi Level w/ Smart Engage (Pat. No: US06556683)	x
INPUT SWITCH	Input Sense 100mV-1V/1V-10V	x
INPUT SWITCH	Input Select 2/4 channel	x
GAIN CONTROL	Stereo - 100mV-10V	x
CROSSOVER	Hi,12dB / Low, 24dB Mono @ 85Hz, Defeatable	x
RCA OUTPUT	Sum, Fr/Rr	x
OTHER FEATURES	Remote Subwoofer Level Control Parallelable	x
OTHER FEATURES	Dual Mono Output	x
FUSE RATING	Total	50
FUSE RATING	Quantity x Fuse Value	2 x 25
DIMENSIONS	Width	12-11/16"
	Depth	9-5/8"
	Height	2-1/2"
