1000XD Specifications |
| Primary Ratings |
| Power Output |
700 Watts RMS x 1 Channel at 4 Ohms < 1% THD+N |
| Signal-to-noise Ratio (1 Watt) |
>75 dB |
| |
| Secondary Ratings |
| Power Output |
1000 Watts RMS x 1 Channel at 2 Ohms < 1% THD+N |
| |
| THD+N (Distortion) (1 Watt) |
<1% |
| Frequency Response (-3dB) |
20Hz to 200Hz |
| Maximum Input Signal |
4V |
| Maximum Sensitivity |
250mV |
| Dimensions |
9-1/8" X 15" X 2-1/4" |
| |
| Mono Gain Control |
| Crossover |
Low @ 40Hz to 200Hz, 24dB/Oct |
| Subsonic |
20Hz to 50Hz,12dB/Oct, Variable |
| Bass Boost |
+12dB @ 40Hz |
| Remote Subwoofer Level Control |
| Smart Engage |
No |
