| TCE4512X2D Enclosure Specifications |
| Model |
TCE4512X2D |
| Description |
Dual 12", T4500 Loaded
Vented Enclosure |
| Impedance |
2 Ω |
| Frequency Response (± 3dB) |
44-150Hz |
| MAX Power |
1350W |
Recommended Amp Power
(MAX) |
675-1350W |
| RMS Power |
450W |
Recommended Amp Power
(RMS) |
225-450W |
| Enclosure Size |
15.75"H x 31.75"W x
18.75"BD x 15.97"TD |
| TCE4510X2D Enclosure Specifications |
| Model |
TCE4510X2D |
| Description |
Dual 10", T4500 Loaded
Vented Enclosure |
| Impedance |
2 Ω |
| Frequency Response (± 3dB) |
44-150Hz |
| MAX Power |
1350W |
Recommended Amp Power
(MAX) |
675-1350W |
| RMS Power |
450W |
Recommended Amp Power
(RMS) |
225-450W |
| Enclosure Size |
14.75"H x 29.75"W x
16.75"BD x 14.15"TD |
| TCE4512A Enclosure Specifications |
| Model |
TCE4512A |
| Description |
12", T4500 Loaded
Vented Enclosure |
| Impedance |
4 Ω |
| Frequency Response (± 3dB) |
42-150Hz |
| MAX Power |
675W |
Recommended Amp Power
(MAX) |
337.5-675W |
| RMS Power |
225W |
Recommended Amp Power
(RMS) |
112.5-225W |
| Enclosure Size |
15.75"H x 25.75"W x
15.75"BD x 13"TD |
| TCE4510A-T Enclosure Specifications |
| Model |
TCE4510A-T |
| Description |
10", T4500 Loaded
Vented Truck Enclosure |
| Impedance |
4 Ω |
| Frequency Response (± 3dB) |
55-150Hz |
| MAX Power |
675W |
Recommended Amp Power
(MAX) |
337.5-675W |
| RMS Power |
225W |
Recommended Amp Power
(RMS) |
112.5-225W |
| Enclosure Size |
14.25"H x 22.25"W x
8.5"BD x 4.43"TD |
|
 |
|
|
