With a reputation for quality and performance in amps and subs and MTX Audio's new breed of subwoofers cranking out more bass than ever, the time has come to enhance the world of coaxial speakers. Introducing Thunder Dome-Axials™—a line that offers crystal clear sound and ease of installation to complement the legendary MTX bass.

MTX Thunder Dome-Axials™ have been engineered to provide ease of installation for direct OEM replacement applications while offering extremely accurate music reproduction. All models from the 4" up to the 6" x 8" feature a 20mm soft dome tweeter (the tweeter swivels on the larger speakers) for an improved listening experience. The 2-way 6" x 9" model has a 25mm soft dome tweeter and the 3-way has a 20mm and a 25mm soft dome tweeter.

The TDX6802 6" x 8" speaker model doubles as a 5" x 7" speaker. Instead of the more common filler plate, MTX designed the speaker so that it could be mounted in factory locations of both 5" x 7" speakers and 6" x 8" speakers using a truly innovative wide mounting flange.

All models of the Thunder Dome-Axial™ line are designed to be installation friendly and have one of the shallowest mounting depths available. A newly designed graphite style grille (on select models) sets off the aluminum deposition cone of the speaker giving the Thunder Dome-Axial™ speakers a look that demands attention to go along with their high performance standards.

Thunder Dome-Axial Specifications

Thunder Dome-Axial TDX6903 Specifications
Model TDX6903
Description 6" x 9" Triaxial
Cone Polypropylene
Tweeter 20 & 25mm Soft Dome
Pivoting Tweeter No
Impedance 4 Ω
Frequency Response 42Hz-20kHz
Power (RMS) 100
Peak Music Power 200
Sensitivity @ 2.83V 92dB
Mounting Depth 3"
Cut-out Diameter 5-15/16" x 8-3/4"
Grille Yes
Thunder Dome-Axial TDX6902 Specifications
Model TDX6902
Description 6" x 9" Coaxial
Cone Polypropylene
Tweeter 25mm Soft Dome
Pivoting Tweeter Yes
Impedance 4 Ω
Frequency Response 42Hz-20kHz
Power (RMS) 100
Peak Music Power 200
Sensitivity @ 2.83V 92dB
Mounting Depth 3"
Cut-out Diameter 5-15/16" x 8-3/4"
Grille Yes
Thunder Dome-Axial TDX6802 Specifications
Model TDX6802
Description 6" x 8" / 5" x 7" Coaxial
Cone Polypropylene
Tweeter 20mm Soft Dome
Pivoting Tweeter Yes
Impedance 4 Ω
Frequency Response 45Hz-20kHz
Power (RMS) 60
Peak Music Power 120
Sensitivity @ 2.83V 92dB
Mounting Depth 2-7/16"
Cut-out Diameter 5" x 7-3/16"
Grille No
Thunder Dome-Axial TDX6502 Specifications
Model TDX6502
Description 6-1/2" (6-3/4") Coaxial
Cone Polypropylene
Tweeter 20mm Soft Dome
Pivoting Tweeter Yes
Impedance 4 Ω
Frequency Response 48Hz-20kHz
Power (RMS) 60
Peak Music Power 120
Sensitivity @ 2.83V 92dB
Mounting Depth 2-1/16"
Cut-out Diameter 5"
Grille Yes
Thunder Dome-Axial TDX5202 Specifications
Model TDX5202
Description 5-1/4" Coaxial
Cone Polypropylene
Tweeter 20mm Soft Dome
Pivoting Tweeter Yes
Impedance 4 Ω
Frequency Response 55Hz-20kHz
Power (RMS) 45
Peak Music Power 90
Sensitivity @ 2.83V 92dB
Mounting Depth 2-1/8"
Cut-out Diameter 4-11/16"
Grille Yes
Thunder Dome-Axial TDX4602 Specifications
Model TDX4602
Description 4" x 6" Coaxial
Cone Polypropylene
Tweeter 20mm Soft Dome
Pivoting Tweeter No
Impedance 4 Ω
Frequency Response 80Hz-20kHz
Power (RMS) 40
Peak Music Power 80
Sensitivity @ 2.83V 92dB
Mounting Depth 2"
Cut-out Diameter 3-5/8" x 5-5/8"
Grille No
Thunder Dome-Axial TDX4002 Specifications
Model TDX4002
Description 4" Coaxial
Cone Polypropylene
Tweeter 20mm Soft Dome
Pivoting Tweeter No
Impedance 4 Ω
Frequency Response 75Hz-20kHz
Power (RMS) 35
Peak Music Power 70
Sensitivity @ 2.83V 92dB
Mounting Depth 1-1/16"
Cut-out Diameter 3-3/4"
Grille Yes
Thunder Dome-Axial TDX3502 Specifications
Model TDX3502
Description 3-1/2" Coaxial
Cone Polypropylene
Tweeter 20mm PEI
Pivoting Tweeter No
Impedance 4 Ω
Frequency Response 83Hz-20kHz
Power (RMS) 25
Peak Music Power 50
Sensitivity @ 2.83V 92dB
Mounting Depth 1-1/2"
Cut-out Diameter 3-1/16"
Grille No
