MTX’s Thunder Axe Separates are available in three models, TX6001, TX5001 and TX4001 and offer a 6-1/2", 5-1/4" or 4" woofer (respectively) featuring a polypropylene cone with aluminum deposition. Each offers a 2-way, 12dB/octave high-quality crossover network that is designed and optimized for off-axis or on-axis listening. Models also include a tunable tweeter network allowing for optimum imaging regardless of placement or positioning. And if you’re looking for a tweeter-only model, the TX1000 is perfect for any application.

These separates offer unmatched features and sonic realism in their class. MTX has been recognized for the performance and quality of our woofer lines for years and now we have stepped up to the plate with these Thunder Axe Separates.

  • Polypropylene cones with aluminum deposition are durable, efficient, and create dynamic sound.

  • 25mm soft dome tweeter can be mounted anywhere to improve imaging and exceed expectations, with the ability to clearly recreate the crispest highs.

  • The specially designed crossover uses mylar capacitors for superior signal integrity.

Thunder Axe Separates Specifications

Thunder Separates TX6001 Specifications
Model TX6001
Description 6-1/2" Separate
Cone Polypropylene with Aluminum Deposition
Tweeter 25mm Soft Dome
Impedance 4 Ω
Frequency Response 44Hz-20kHz
Power (RMS) 90
Peak Music Power 180
Sensitivity @ 2.83V 90dB
Voice Coil 1"
X-Max 2.75mm
Woofer Mounting Depth 2-3/16"
Woofer Cut-out Diameter 5"
Tweeter Mounting Depth 1"
Tweeter Cut-out Diameter 1-7/8"
Tweeter Mounting Options Flush, Surface, Angle
Crossover 2-Way. 18dB/6dB
Adjustable Tweeter Level 0, -3
Thunder Separates TX5001 Specifications
Model TX5001
Description 5-1/4" Separate
Cone Polypropylene with Aluminum Deposition
Tweeter 25mm Soft Dome
Impedance 4 Ω
Frequency Response 51Hz-20kHz
Power (RMS) 90
Peak Music Power 180
Sensitivity @ 2.83V 90dB
Voice Coil 1"
X-Max 2.75mm
Woofer Mounting Depth 2-3/16"
Woofer Cut-out Diameter 4-11/16"
Tweeter Mounting Depth 1"
Tweeter Cut-out Diameter 1-7/8"
Tweeter Mounting Options Flush, Surface, Angle
Crossover 2-Way. 18dB/6dB
Adjustable Tweeter Level 0, -3
Thunder Separates TX4001 Specifications
Model TX4001
Description 4" Separate
Cone Polypropylene with Aluminum Deposition
Tweeter 25mm Soft Dome
Impedance 4 Ω
Frequency Response 74Hz-20kHz
Power (RMS) 75
Peak Music Power 150
Sensitivity @ 2.83V 90dB
Voice Coil 1"
X-Max 1.5mm
Woofer Mounting Depth 1-7/8"
Woofer Cut-out Diameter 3-3/4"
Tweeter Mounting Depth 1"
Tweeter Cut-out Diameter 1-7/8"
Tweeter Mounting Options Flush, Surface, Angle
Crossover 2-Way. 18dB/6dB
Adjustable Tweeter Level 0, -3
Thunder Separates TX1000 Specifications
Model TX1000
Description 25mm Tweeter
Cone N/A
Tweeter 25mm Soft Dome
Impedance 4 Ω
Frequency Response 2.5kHz-20kHz
Power (RMS) 50
Peak Music Power 100
Sensitivity @ 2.83V 90dB
Voice Coil 25mm
X-Max N/A
Woofer Mounting Depth N/A
Woofer Cut-out Diameter N/A
Tweeter Mounting Depth 1"
Tweeter Cut-out Diameter 1-7/8"
Tweeter Mounting Options Flush, Surface, Angle
Crossover 1-Way. 18dB
Adjustable Tweeter Level N/A
