| JH4512-04 Subwoofer Specifications |
| |
|
| Model |
JH4512-04 |
| Description |
12" Subwoofer |
| Impedance |
4 Ω |
| RMS Power (Watts) |
250 |
Rec. RMS Amplifier
Power (Watts) |
125 - 250 |
| Sensitivity |
86.8db |
| Voice Coil |
1.5" |
| Magnet Weight (oz.) |
48 |
| Mounting Depth |
5-1/2" |
| Cut Out Diameter |
11-1/16" |
Sealed Enclosure
Net Volume |
1.25ft³ |
Vented Enclosure
Net Volume |
2.0ft³ |
| Speaker Displacement (in³) |
31.27 |
| Tuning Frequency |
35Hz |
| JH4510-04 Subwoofer Specifications |
| |
|
| Model |
JH4510-04 |
| Description |
10" Subwoofer |
| Impedance |
4 Ω |
| RMS Power (Watts) |
200 |
Rec. RMS Amplifier
Power (Watts) |
100 - 200 |
| Sensitivity |
86.4db |
| Voice Coil |
1.5" |
| Magnet Weight (oz.) |
48 |
| Mounting Depth |
4 17/20" |
| Cut Out Diameter |
9 17/100" |
Sealed Enclosure
Net Volume |
75ft³ |
Vented Enclosure
Net Volume |
1.45ft³ |
| Speaker Displacement (in³) |
21.8 |
| Tuning Frequency |
39Hz |
|  |
|
|
