| JH5512-04 Subwoofer Specifications |
| |
|
| Model |
JH5512-04 |
| Description |
12" Subwoofer |
| Impedance |
4 Ω |
| RMS Power (Watts) |
400 |
Rec. RMS Amplifier Power (Watts) |
200 - 400 |
| Sensitivity |
86.7 |
| Voice Coil |
1.75" |
| Magnet Weight (oz.) |
70 |
| Mounting Depth |
6 83/100" |
| Cut Out Diameter |
11-1/16" |
Sealed Enclosure Net Volume |
1.25ft³ |
Vented Enclosure Net Volume |
2.0ft³ |
| Speaker Displacement (in³) |
49.68 |
| Tuning Frequency |
35Hz |
|  |
|
|
