DCM TD822C 8 inch 2-Way 75W RMS 8 Ohm In-Ceiling Loudspeaker with Stereo Input

Home Audio - Custom DCM In-Ceiling Speakers

TD822C Custom Stereo Speaker

Rich, deep music throughout your home

8" 2-Way 75W RMS 8 Ohm In-Ceiling Loudspeaker with Stereo Input/Output

Rivals Hifi Tower Speakers

Utilizing DCM “Wide Dispersion” Design, One Voice Technology and audiophile components to provide rich sound throughout the area.

Availability: In stock
SKU: TD822C
$249.95
Share this MTX page...

DCM “Wide Dispersion” Design

Rich Sound Filling The Entire Area

One Voice Technology

Creates Exact Sonic Signatures Between All Models

Audiophile Components

Kevlar Woofers, Pivoting Teteron Tweeters and Neodymium Magnets

TD822C Key Features

  • DCM “Wide Dispersion” Design
  • One Voice Technology Creates Exact Sonic Signatures Between All Models
  • Kevlar Woofers
  • Pivoting Teteron Tweeters
  • Neodymium Magnets
  • 2nd Order 12dB Crossover
  • Push Spring Terminals
  • Paintable Fine Mesh Grilles
  • Debris Resistant Basket

High-Performance, TimeDomain Series - Distributed Audio

Architectural Design, Audiophile Sound

This large DVC model features the same performance enhancements and quality materials as its 8" single channel companion, the TD820C, but with 2-channel inputs this powerhouse can fly solo and still play stereo sound. They are great for listening areas with space limitations and non-dedicated listening positions.

DCM's TimeDomain series offers great architectural models for premium whole home audio and additional sound solutions. Designed and tooled to be consistent with the other top lines of the DCM brand, these models add flexibility and expand the distributed audio options for those who demand accuracy and musical purity throughout.

Features
  • 8" Kevlar Woofer with Rubber Surround
  • 2 20MM Teteron Dome Tweeters
  • Dual Voice Coil (Stereo)
  • Neodymium Magnet
  • 2nd Order 12dB/Octave Crossover
  • Wide Desperision Design
  • Swivel Style Mounting Wings
  • Spring Push Terminals
  • Paintable Fine Mesh Grilles
  • Debris Resistant Basket
Tech Specs
Woofer Single 8" Kevlar
Tweeter Dual 20 mm Teteron Dome
RMS Power (Watts) 75
Peak Music Power (Watts) 150
Frequency Response 50Hz - 20kHz
Sensitivity 91.3dB
Mounting Depth 3 1/2" (8.89 cm)
Cut Out Size 9 1/2" (24.1 cm)
Support Files
AW0011910 (6 pages) View |  Download
