X603 xtant 300W RMS 3 Channel Amplifier

Car Audio Amplifiers

X603 xtant

Three channels of raw power

Xtant has long been known as the pinnacle of quality in the car audio industry. Known for high end features and cosmetics, Xtant stands apart with its innovative use of materials and focus on sound quality.

Availability: In stock
SKU: X603
Sold Individually
1,599.95
600.00
999.95
Share this MTX page...

    Xtant has long been known as the pinnacle of quality in the car audio industry. Known for high end features and cosmetics, Xtant stands apart with its innovative use of materials and focus on sound quality.

    The X603 is a “true” three (') channel amplifier which combines unique performance features with outstanding design flexibility to provide a single chassis “system solution” for most mobile audio applications* With its on+board crossover, a high performance, bi+amplified system is easily configured.

    By utilizing the on+board crossover’s four (") RCA line outputs, you can steer specific frequency ranges to additional amplifiers, thus eliminating the need for external, active crossover components.

    As with all Xtant “X” Series amplifiers, the X%(' incorporates an on+board noise gate, forced convection thermal management system, and a Pulse Width Modulated power supply for high efficiency and unsurpassed reliability. All these features are encased in Xtant’s exclusive stainless steel housing*



    Features
    Forced Convection Cooling
    Fully Regulated PWM Power Supply
    Selectable Crossover - Full Range, High Pass, Low Pass
    Noise Gate
    Balanced/Floating Input
    Modular Expansion Port
    Thermal, Overcurrent, and Low Voltage Protection Circuitry
    Passiver Output
    Status LEDs
    Tech Specs
    4 Ohm RMS Power Output 2 x 75 + 1 x 150
    2 Ohm RMS Power Output 2 x 150 + 1 x 300
    Frequency Response 20Hz - 20kHz
    THD <0.2%
    Signal to Noise Ratio > 100dB
    Maximum Input Signal 8.5V Unbalanced, 17V Balanced
    Length 20-21/32" (525mm)
    Width 8-7/8" (225.4mm)
    Depth 2-7/32" (55mm)
    Support Files
    X603 Owners Manual (19 pages) View | Download
